| Model |
Enthoo Pro 2 Server V2 |
| Part Number |
PH-ES620PC_BK03 |
| UPC |
886523304173 |
| Colour |
Black |
| Case Type |
Full-Tower |
| Dimensions (D × W × H) |
570 × 240 × 550 mm |
| Materials |
Steel Chassis + Aluminum Panels + ABS |
| Motherboard Support |
SSI-EEB / XL-ATX / E-ATX / ATX / Micro-ATX / Mini-ITX |
| Expansion Slots |
11 |
| Vertical GPU Support |
Yes |
| GPU Riser |
Sold separately |
| GPU Length |
Up to 503 mm |
| CPU Cooler Height |
Up to 195 mm |
| PSU Support |
ATX + Server PSU |
| 2.5" Storage Positions |
11 |
| 3.5" Storage Positions |
10 |
| Additional Storage |
2 × 3.5" HDD + 3 × 2.5" SSD |
| Included HDD Brackets |
4 × Stackable HDD Brackets |
| Included SSD Brackets |
3 × SSD Brackets |
| Included Fans |
None |
| Top Fans |
3 × 120 / 3 × 140 mm |
| Front Fans |
4 × 120 / 3 × 140 mm |
| Side Fans |
4 × 120 mm |
| Optional Left-Side Bracket |
3 × 120 mm |
| Rear Fans |
1 × 120 / 1 × 140 mm |
| Maximum Fans |
15 × 120 / 6 × 140 mm |
| Top Radiator |
Up to 360 / 280 mm |
| Front Radiator |
Up to 480 / 420 mm |
| Side Radiator |
Up to 480 mm |
| Rear Radiator |
Up to 120 mm |
| Top Radiator Clearance |
475 × 120 × 55 mm |
| Side Radiator Clearance |
525 × 134 × 35 mm |
| Tempered Glass |
No — Closed Panel |
| D-RGB |
No |
| Front I/O |
2 × USB 3.0 + 1 × USB-C 3.2 Gen2x2 |
| Audio |
Microphone / Headphone Combo |
| Controls |
Power / Reset |
| Net Weight |
11.32 kg |
| Gross Weight |
13.14 kg |
| Warranty |
5 Years Limited |
