| Model |
PH-ES524S2_DBK01 |
| Product Name |
Evolv S2 |
| Color |
Black |
| Case Type |
Mid-Tower |
| Dimensions |
455 × 230 × 525 mm |
| Materials |
Steel chassis, Tempered Glass, ABS |
| Motherboard Support |
E-ATX, ATX, Micro-ATX, Mini-ITX |
| Max E-ATX Width |
280 mm |
| Rear-Connect Motherboard |
ATX supported |
| Expansion Slots |
7 |
| Vertical GPU Support |
Yes |
| Riser Cable / Bracket |
Sold separately |
| Max GPU Length |
395 mm |
| Max GPU Width |
175 mm |
| Max CPU Cooler Height |
175 mm |
| Max PSU Length |
210 mm |
| 2.5" Drive Support |
2 |
| 3.5" Drive Support |
2 |
| Fan Support |
Up to 7 × 120 mm |
| Top Fan Support |
3 × 120 mm |
| Mid-Plate Fan Support |
3 × 120 mm |
| Rear Fan Support |
1 × 120 mm |
| Included Fans |
4 × M25-120 D-RGB |
| Included Fan Configuration |
1 × Regular + 3 × Reverse |
| Top Radiator Support |
Up to 360 mm |
| Max Top Radiator Size |
410 × 125 × 55 mm |
| D-RGB |
Integrated D-RGB lighting strips |
| Front I/O |
2 × USB 3.0, 1 × USB-C 3.2 Gen2x2 |
| Audio |
1 × Microphone/Headphone Combo |
| Buttons |
Power + Reset |
| Net Weight |
9.9 kg |
| Warranty |
5 Years Limited |
