| Model |
NV5S |
| Part Number |
PH-NV523S_DBK01 |
| Colour |
Black |
| Case Type |
Mid-Tower |
| Materials |
Steel Chassis + Tempered Glass |
| Dimensions (W × D × H) |
218 × 450 × 505 mm |
| Motherboard Support |
E-ATX, ATX, Micro-ATX, Mini-ITX |
| E-ATX Support |
Up to 280 mm |
| Expansion Slots |
7 |
| Vertical GPU Support |
Yes, optional bracket/riser required |
| GPU Length |
Up to 430 mm |
| GPU Width |
Up to 170 mm |
| CPU Cooler Height |
Up to 170 mm |
| PSU Support |
ATX |
| Max PSU Length |
195 mm |
| 3.5" Drive Bays |
1 |
| 2.5" Drive Bays |
3 |
| Included Fans |
4 × 120 mm M25 D-RGB |
| Top Fan Support |
3 × 120 mm |
| Side Fan Support |
3 × 120 mm |
| Rear Fan Support |
1 × 120 mm |
| Total Fan Capacity |
7 × 120 mm |
| Top Radiator Support |
Up to 360 mm |
| Side Radiator Support |
Up to 360 mm |
| Rear Radiator Support |
Up to 120 mm |
| D-RGB |
Integrated Digital-RGB |
| D-RGB Controller |
Integrated, software-free controller |
| Front I/O |
2 × USB 3.0, 1 × USB-C Gen2, Mic/Headphone Combo |
| Controls |
Power, Reset, D-RGB Mode, D-RGB Colour |
| Tempered Glass |
Front + Side |
| GPU Support Bracket |
Included |
| Dust Filtration |
Ultra-fine mesh ventilation |
| Net Weight |
Approx. 8.3–8.35 kg |
| Warranty |
5 Years Limited |
