| Model |
NV7 |
| Part Number |
PH-NV723TG_DMW01_RU |
| Colour |
Matte White |
| Case Type |
Full Tower |
| Materials |
Steel Chassis + Tempered Glass Front & Side Panels |
| Dimensions (D × W × H) |
532 × 253 × 586 mm |
| Volume |
Approx. 79 L |
| Motherboard Support |
E-ATX, ATX, Micro-ATX, Mini-ITX, SSI-CEB |
| E-ATX Support |
Up to 277 mm wide |
| Expansion Slots |
8 |
| GPU Length |
Up to 450 mm |
| CPU Cooler Height |
Up to 185 mm |
| PSU Support |
ATX |
| Max PSU Length |
Up to 255 mm |
| Drive Bays |
2 × 3.5" + 6 × 2.5" |
| Front Fans |
Not supported |
| Side Fans |
Up to 4 × 120 mm |
| Top Fans |
Up to 3 × 120 mm |
| Bottom Fans |
Up to 3 × 120/140 mm |
| Rear Fans |
Up to 2 × 120 mm |
| Radiator Support |
Top / Side / Bottom / Rear |
| Top Radiator |
Up to 360 mm |
| Side Radiator |
Up to 360 mm |
| Bottom Radiator |
Up to 360 mm |
| Rear Radiator |
Up to 240 mm |
| Included Fans |
None |
| RGB |
Integrated D-RGB |
| D-RGB Control |
Case buttons + motherboard synchronization |
| Front I/O |
1 × USB-C 3.2 Gen2, 2 × USB-A 3.2 Gen1, Audio Combo Jack |
| RGB Controls |
D-RGB Mode / Colour / Speed / Channel |
| Tempered Glass |
Front + Left Side |
| Dust Filters |
Top, Bottom, Side and Rear |
| Vertical GPU |
Supported with optional bracket/riser |
| Back-Connect Motherboard |
Not supported |
| Weight |
Approx. 16.9 kg |
| PSU Position |
Top-mounted, concealed |
| Warranty |
5 Years |
