| Model |
XT View |
| Part Number |
PH-XT523V1_DBK01 |
| Colour |
Satin Black |
| Case Type |
Mid-Tower |
| Dimensions (D × W × H) |
440 × 230 × 500 mm |
| Materials |
Steel Chassis + Tempered Glass + ABS |
| Motherboard Support |
E-ATX / ATX / Micro-ATX / Mini-ITX |
| E-ATX Support |
Up to 280 mm wide |
| Rear-Connector Motherboard |
MSI Project Zero / ASUS BTF / Gigabyte Project Stealth |
| Tempered Glass |
Front + Side |
| Expansion Slots |
7 |
| Vertical GPU Support |
3-Slot |
| GPU Riser |
Sold separately |
| GPU Length |
Up to 415 mm |
| GPU Width |
Up to 184 mm |
| CPU Cooler Height |
Up to 184 mm |
| PSU Length |
Up to 270 mm |
| 2.5" Drive Bays |
5 + 1 × 3.5" HDD |
| 3.5" Drive Bays |
2 + 3 × 2.5" SSD |
| Included Fans |
3 × M25-120 D-RGB |
| Top Fans |
3 × 120 mm / 2 × 140 mm |
| Side Fans |
2 × 120 mm |
| Midplate Fans |
3 × 120 mm |
| Rear Fans |
1 × 120 mm / 1 × 140 mm |
| Maximum Fans |
9 × 120 mm / 3 × 140 mm |
| Top Radiator |
Up to 360 mm |
| Side Radiator |
Up to 240 mm* |
| Rear Radiator |
120 mm |
| Front Radiator |
Not supported |
| D-RGB |
Integrated |
| D-RGB Controller |
Built-in |
| Front I/O |
1 × USB-C 3.2 Gen2 + 1 × USB 3.0 |
| Audio |
Microphone / Headphone Combo |
| Controls |
Power / Reset / D-RGB Mode / D-RGB Colour |
| Net Weight |
7.55 kg |
| Gross Weight |
9.45 kg |
| Warranty |
5 Years Limited |
