| Model |
PH-XT525V_DBK01 |
| Product Name |
XT V5 |
| Color |
Black |
| Case Type |
Mid-Tower |
| Dimensions |
452 × 235 × 430 mm |
| Materials |
Steel Chassis, Tempered Glass, ABS Plastic |
| Motherboard Support |
ATX, Micro-ATX, Mini-ITX |
| Expansion Slots |
7 |
| Vertical GPU Support |
No |
| GPU Support Bracket |
Included |
| Max GPU Length |
430 mm |
| Max GPU Width |
175 mm |
| Max CPU Cooler Height |
175 mm |
| Max PSU Length |
159 mm |
| 2.5" Drive Support |
2 |
| 3.5" Drive Support |
1 |
| Fan Support |
Up to 7 × 120 mm |
| Top Fan Support |
3 × 120 mm |
| Bottom Fan Support |
3 × 120 mm |
| Rear Fan Support |
1 × 120 mm |
| Included Fans |
1 × S25-120 D-RGB + 1 × S25-360 D-RGB |
| Included Fan Layout |
1 × Rear 120 mm + 3 × Bottom 120 mm |
| Top Radiator Support |
Up to 360 mm |
| Max Top Radiator Size |
410 × 122 × 38 mm |
| Front Radiator Support |
No |
| Rear Radiator Support |
No |
| Bottom Radiator Support |
No |
| Front Panel |
Tempered Glass |
| Side Panel |
Tempered Glass |
| D-RGB |
Yes |
| Front I/O |
1 × USB 3.0, 1 × USB-C 3.2 Gen2x2 |
| Audio |
Microphone / Headphone Combo |
| Buttons |
Power + Reset |
| Net Weight |
7.05 kg |
| Gross Weight |
8.36 kg |
| Warranty |
5 Years Limited |
