Specification Details
Fan Size: 140 × 140 mm
Thickness: 16 mm (slim profile)
Speed Range: 120–1800 RPM (PWM controlled)
Zero RPM Mode: Yes, stops below 9% PWM
Airflow: 47 CFM (79.85 m³/h)
Static Pressure: 1.31 mmH₂O
Bearing Type: Fluid Dynamic Bearing (FDB)
Noise Level: 0.3 Sone
Connector: 4-pin PWM + 4-pin PST daisy-chain connector
Rated Voltage: 12 V DC
Startup Voltage: 4 V DC
Current Draw: 0.19 A
Cable Length: 400 mm + 80 mm PST extension
Weight: 130 g
Warranty: 6 Years
