⚡ Key Features
Processor & Power Delivery
-
Socket AM5 Support: Ready for AMD Ryzen™ 9000, 8000, and 7000 Series Processors.
-
Robust VRM Architecture: Features a 12+2+1 Power Phase design equipped with Dr.MOS for VCore, SOC, and MISC to provide stable power distribution under load.
Memory & Expansion Slots
-
High-Speed DDR5: Houses 4x DDR5 DIMM slots supporting Dual Channel architecture with overclocked speeds reaching 8000+ (OC) MT/s.
-
PCIe 5.0 Core Lane: Outfitted with 1x PCIe 5.0 x16 slot for next-generation graphics cards, supplemented by 1x PCIe 4.0 x16 slot and 2x PCIe 4.0 x1 slots.
Next-Gen Storage & Thermals
-
Blazing M.2 Access: Provides 1x Blazing M.2 slot operating on high-bandwidth PCIe Gen5 x4 lanes, alongside 1x Hyper M.2 slot (PCIe Gen4 x4) and 4x SATA3 connectors.
-
Advanced Passive Cooling: Built with an integrated toolless multi-layer M.2 heatsink module and an M.2 bottom heatsink for sustained storage performance.
Networking & High-Speed I/O
-
Wi-Fi 7 Integration: Features cutting-edge 802.11be Wi-Fi 7 and Bluetooth capabilities for modern high-bandwidth wireless networking.
-
2.5GbE Wired LAN: Equipped with a Realtek 2.5Gbps ethernet port for low-latency wired connections.
-
USB Connectivity: Includes a versatile array of ports, notably featuring a USB 3.2 Gen2 Type-C port on the rear panel and a USB 3.2 Gen1 Type-C header for front panel chassis routing.
