⚡ Key Features
🔲 Next-Gen Processor & Platform Support
LGA1851 Socket Readiness: Built specifically to house the latest Intel® Core™ Ultra Processors (Series 2).
Dedicated AI Processing: Seamlessly handles advanced AI workloads utilizing the processor's integrated NPU acceleration.
download.asrock.com
Power Phase Optimization: Engineered with a reliable 5+1+1+1+1 power phase layout alongside Digi Power configuration to ensure continuous system stability under computing loads.
🏎️ High-Speed Memory & Expansion Layout
Dual Channel DDR5 Compatibility: Features 2x DDR5 DIMM slots supporting maximum configuration capacities up to 128GB and massive overclocking limits reaching 8333+ (OC) MT/s.
PCIe 5.0 Core Lane Architecture: Equipped with a primary high-bandwidth PCIe 5.0 x16 expansion slot dedicated to next-generation graphics cards, as well as an additional PCIe 4.0 x1 slot.
💾 Storage Solutions & Thermals
Blazing Gen5 M.2 Capabilities: Features 1x Blazing M.2 socket running on high-speed PCIe Gen5 x4 lanes (128 Gb/s) for flagship NVMe storage.
download.asrock.com
Secondary Storage Expansion: Outfitted with 1x Hyper M.2 socket (PCIe Gen4 x4) and 4x SATA3 6.0 Gb/s connectors with full RAID 0/1/5/10 data protection capabilities.
Optimized Heatsinks: Includes aluminum hardware cooling arrays coupled with smart fan header technology that auto-detects PWM or DC cooling hardware lines.
www.asrock.com
🌐 High-Speed Connectivity & External I/O
Wi-Fi 6E Wireless Core: Integrates an 802.11axe Wi-Fi 6E module utilizing the extended 6GHz spectrum band, plus Bluetooth 5.3.
download.asrock.com
Dragon 2.5G LAN: Managed by a Realtek 2.5 Gigabit ethernet chip with prioritized visual bandwidth management control utilities.
Reversible USB Setup: Features a massive 20 Gb/s USB 3.2 Gen2x2 Type-C port directly built into the rear panel panel alongside front-panel USB 3.2 Gen1 Type-C chassis integration headers.
download.asrock.com
Display Output Array: Preconfigured for up to 4K @ 120Hz via an HDMI 2.1 TMDS port and up to 8K @ 60Hz via DisplayPort 1.4 connection configurations.
download.asrock.com
🎨 Audio & DIY Integration
Sound Engine: Powered by a Realtek ALC897 7.1 Channel High Definition Audio configuration.
Polychrome RGB Sync: Houses onboard customizable 12V RGB headers and dual 5V Addressable ARGB infrastructure lines to let you sync up chassis custom illumination layouts.
