| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Maximum CPU TDP |
Up to 170W |
| Chipset |
AMD B840 |
| Form Factor |
ATX — 30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
256GB |
| Memory Speed |
Up to 7600+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS AEMP |
| Main PCIe Slot |
1 × PCIe 4.0 x16 |
| Additional PCIe Slots |
1 × PCIe 3.0 x16 (x4) + 2 × PCIe 3.0 x16 (x1) + 1 × PCIe 3.0 x1 |
| M.2 Slots |
3 × M.2 |
| M.2 Gen4 |
2 × PCIe 4.0 x4 |
| M.2 Gen3 |
1 × PCIe 3.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Realtek 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 6E |
| Wi-Fi Configuration |
2×2 Wi-Fi 6E, 2.4 / 5 / 6GHz |
| Bluetooth |
Bluetooth 5.3 |
| Rear USB |
2 × USB 10Gbps (1 × Type-A + 1 × |
