| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Maximum CPU TDP |
Up to 170W |
| Chipset |
AMD B840 |
| Form Factor |
Micro-ATX — 24.4 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
256GB |
| Memory Speed |
Up to 7600+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS AEMP |
| Main PCIe Slot |
1 × PCIe 4.0 x16 |
| Additional PCIe Slots |
2 × PCIe 3.0 x16 (x1 mode) |
| M.2 Slots |
3 × M.2 |
| M.2 Gen4 |
2 × PCIe 4.0 x4 |
| M.2 Gen3 |
1 × PCIe 3.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Realtek 2.5Gb Ethernet |
| Wi-Fi |
No built-in Wi-Fi |
| Bluetooth |
No built-in Bluetooth |
| Rear USB |
2 × USB 10Gbps Type-A + 1 × USB 5Gbps Type-C + 4 × USB 2.0 Type-A |
| Front USB |
1 × USB 5Gbps Type-C header + 1 × USB 5Gbps header (2 ports) + 2 × USB 2.0 headers (4 ports) |
| Display Output |
2 × DisplayPort + 1 × HDMI |
| Audio |
Realtek 7.1-channel High Definition Audio Codec |
| Audio Support |
Up to 24-bit / 192kHz playback |
| Power Design |
8+2+1 Phase Digital Power Design |
| PCB |
6-layer PCB |
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS |
| BIOS FlashBack |
Yes |
| RGB |
3 × Addressable Gen 2 RGB headers |
| CSM |
ASUS Corporate Stable Model |
| IT Management |
ASUS Control Center Express |
