| Brand |
ASUS PRIME |
| Graphics Engine |
NVIDIA GeForce RTX 5070 Ti |
| Architecture |
NVIDIA Blackwell |
| CUDA Cores |
8,960 |
| AI Performance |
1,406 TOPs |
| Bus Standard |
PCI Express 5.0 |
| Video Memory |
16GB GDDR7 |
| Memory Speed |
28 Gbps |
| Memory Interface |
256-bit |
| OC Mode Clock |
2,527 MHz |
| Default Boost Clock |
2,497 MHz |
| OpenGL |
OpenGL 4.6 |
| Maximum Digital Resolution |
7680 × 4320 |
| HDMI |
1 × HDMI 2.1b |
| DisplayPort |
3 × DisplayPort 2.1b |
| Maximum Displays |
4 |
| HDCP |
HDCP 2.3 |
| NVLink / SLI |
Not Supported |
| Cooling |
ASUS PRIME cooling system |
| Slot Size |
2.5-Slot |
| SFF Ready |
Compatible |
| Power Connector |
1 × 16-pin |
| Recommended PSU |
750W |
| Dimensions |
304 × 126 × 50 mm (L × W × H) |
| Software |
ASUS GPU Tweak III, MuseTree, GeForce Game Ready Driver, Studio Driver |
| Accessories |
Speedsetup Manual, ASUS Velcro Hook & Loop, Thank You Card, 1-to-3 Adapter Cable |
