| CPU |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD X870 |
| Memory |
4 × DDR5 DIMM |
| Max Memory |
256GB |
| Memory Speed |
Up to DDR5-8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
AMD EXPO™, ASUS AEMP, ECC / Non-ECC Un-buffered |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| Additional PCIe |
3 × PCIe 4.0 x16 (x1 mode) |
| M.2 |
4 × M.2 |
| M.2 PCIe 5.0 |
1 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
2 × PCIe 4.0 x4 |
| M.2 PCIe 3.0 |
1 × PCIe 3.0 x2 |
| SATA |
2 × SATA 6Gb/s |
| LAN |
Realtek 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Wi-Fi |
2×2, 160MHz, up to 2.9Gbps |
| Bluetooth |
Bluetooth 5.4 |
| USB4 |
2 × USB4 Type-C, up to 40Gbps |
| Rear USB 10Gbps |
1 × USB Type-A |
| Rear USB 5Gbps |
3 × USB Type-A |
| Rear USB 2.0 |
4 × USB Type-A |
| Front USB 10Gbps |
1 × USB Type-C header |
| Front USB 5Gbps |
1 × header, supports 2 additional ports |
| HDMI |
HDMI 2.1, up to 4K@60Hz |
| Audio |
Realtek 7.1-channel High Definition Audio |
| Audio Resolution |
Up to 24-bit / 192kHz |
| Power Design |
14+2+1 power stages, 80A |
| PCB |
8-layer PCB |
| BIOS |
256Mb Flash ROM / BIOS FlashBack™ |
| CSM |
ASUS Corporate Stable Model |
