| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series + AMD EPYC™ 4005 Series |
| Max CPU TDP |
Up to 170W |
| Chipset |
AMD B850 |
| Form Factor |
ATX — 30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Max Memory |
256GB |
| Memory Speed |
Up to 8400+ MT/s OC (Ryzen 9000); 9000+ MT/s OC (Ryzen 8000); 8000+ MT/s OC (Ryzen 7000) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, EXPO, ASUS AEMP |
| Main PCIe |
2 × PCIe 5.0 x16 — x16 single / x8+x8 dual |
| Additional PCIe |
1 × PCIe 4.0 x16 (max x4) + 1 × PCIe 4.0 x1 |
| M.2 |
3 × M.2 |
| M.2 Gen5 |
2 × PCIe 5.0 x4 |
| M.2 Gen4 |
1 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
2 × Realtek 5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Wi-Fi Module |
Realtek RTL8922AE, 2×2, 160MHz |
| Bluetooth |
Bluetooth with LE Audio support |
| Rear USB |
2 × USB 10Gbps Type-C + 2 × USB 10Gbps Type-A + 4 × USB 2.0 Type-A |
| Front USB |
USB 20Gbps Type-C header, up to 30W PD/QC4+ + USB 5Gbps header + 2 × USB 2.0 headers |
| Display Output |
HDMI 2.1 — up to 4K@60Hz; DisplayPort 1.4 — up to 8K@30Hz |
| Audio |
Realtek ALC1220P 7.1-channel |
| Audio Quality |
Up to 120dB SNR playback / 113dB SNR recording |
| Power Design |
14+2+1 power stages, 80A |
| BIOS |
64MB Flash ROM, UEFI AMI BIOS |
| RGB |
3 × Addressable Gen 2 RGB headers |
| USB4 |
Thunderbolt / USB4 header for optional add-on card |
