| Brand |
ASUS |
| Series |
ROG CROSSHAIR |
| Model |
X870E GLACIAL |
| Part Number |
90MB1NQ0-M0UAY0 |
| Chipset |
AMD X870E |
| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen 9000 / 8000 / 7000 Series |
| Form Factor |
E-ATX |
| Dimensions |
30.5 × 27.7 cm (L × W) |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
Up to 256GB |
| Memory Speed |
Up to DDR5-8600+ MT/s OC with Ryzen 9000 |
| Memory Features |
AMD EXPO, ASUS AEMP, NitroPath DRAM, DIMM Fit / DIMM Fit Pro |
| PCIe |
2 × PCIe 5.0 x16 |
| M.2 Slots |
Up to 7 × M.2 |
| M.2 PCIe 5.0 |
Up to 4 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
Additional PCIe 4.0 M.2 slots |
| SATA |
4 × SATA 6Gb/s |
| LAN |
2 × Realtek 10Gb Ethernet |
| Wireless |
Wi-Fi 7 2×2 |
| Bluetooth |
Bluetooth 5.4 |
| USB4 |
2 × USB4 40Gbps Type-C |
| Front USB-C |
USB 20Gbps with up to 60W PD/QC4+ |
| Audio |
ROG SupremeFX 7.1-channel |
| Audio Codec |
Realtek ALC4082 |
| DAC |
ESS ES9219 Quad DAC |
| Display |
Integrated 5-inch Full-Color LCD |
| Power Design |
Extreme ROG power delivery |
| BIOS |
Dual 64MB / 512Mb Flash ROM, UEFI AMI |
