| Model |
ROG CROSSHAIR X870E HERO BTF |
| Part Number |
90MB1MX0-M0UAY0 |
| Form Factor |
ATX |
| Dimensions |
30.5 × 24.4 cm |
| CPU Socket |
AMD Socket AM5 |
| Chipset |
AMD X870E |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series |
| Memory |
DDR5 |
| Memory Slots |
4 × DIMM |
| Max Memory |
256GB |
| Memory Speed |
Up to DDR5-8200+ MT/s (OC) with Ryzen 9000 |
| Memory Profile |
AMD EXPO™, ASUS AEMP |
| PCIe |
1 × PCIe 5.0 x16 |
| Additional PCIe |
1 × PCIe 4.0 x4 |
| M.2 Slots |
5 × M.2 |
| M.2 PCIe 5.0 |
3 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
2 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Intel 2.5Gb Ethernet + Realtek 5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| USB4 |
2 × USB4 Type-C, up to 40Gbps |
| Rear USB 10Gbps |
8 × (6 Type-A + 2 Type-C) |
| Front USB 20Gbps |
2 × USB Type-C headers |
| Audio |
ROG SupremeFX 7.1 / Realtek ALC4082 |
| DAC |
ESS ES9218 Quad DAC |
| HDMI |
1 × HDMI |
| Power Design |
18+2 teamed power stages |
| BTF |
Hidden Connector / Back-Connect design |
| BIOS |
BIOS FlashBack™ + Clear CMOS |
| Warranty |
3 Years |
