| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ Desktop Processors |
| Chipset |
AMD B650 |
| Form Factor |
ATX — 30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
192GB |
| Memory Speed |
Up to 8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS OptiMem II |
| Main PCIe Slots |
2 × PCIe 5.0 x16 — x16 or x8/x4 |
| Additional PCIe Slot |
1 × PCIe 4.0 x16 (x4 mode) |
| M.2 Slots |
4 × M.2 |
| M.2 Gen5 |
2 × PCIe 5.0 x4 |
| M.2 Gen4 |
2 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Intel 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 6E |
| Wi-Fi Configuration |
2×2, 2.4 / 5 / 6GHz |
| Bluetooth |
Bluetooth 5.2 |
| Rear USB |
1 × USB 20Gbps Type-C + 7 × USB 10Gbps (6 × Type-A + 1 × Type-C) + 4 × USB 2.0 |
| Front USB |
1 × USB 10Gbps Type-C + 1 × USB 5Gbps header + 2 × USB 2.0 headers |
| Display Output |
1 × DisplayPort 1.4 + 1 × HDMI 2.1 |
| DisplayPort Support |
Up to 8K@60Hz |
| HDMI Support |
Up to 4K@60Hz |
| Audio |
ROG SupremeFX ALC4080 7.1-channel HD Audio |
| Audio Amplifier |
Savitech SV3H712 |
| Audio Quality |
120dB SNR playback / 113dB SNR recording |
| S/PDIF |
Optical S/PDIF Out |
| Power Design |
16+2+1 Power Stages, rated up to 70A per stage |
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS |
| BIOS FlashBack |
Yes |
| RGB |
3 × Addressable Gen 2 RGB headers + 1 × Aura RGB header |
| Thunderbolt / USB4 |
1 × Thunderbolt™ / USB4® header |
