| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD B650 |
| Form Factor |
Mini-ITX — 17 × 17 cm |
| Memory |
2 × DDR5 DIMM |
| Maximum Memory |
96GB |
| Memory Speed |
Up to 8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS OptiMem II |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| M.2 Slots |
2 × M.2 |
| M.2 Gen5 |
1 × PCIe 5.0 x4 |
| M.2 Gen4 |
1 × PCIe 4.0 x4 |
| SATA |
2 × SATA 6Gb/s |
| LAN |
Intel 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 6E |
| Wi-Fi Configuration |
2×2 Wi-Fi 6E, 2.4 / 5 / 6GHz |
| Bluetooth |
Bluetooth 5.2 |
| Rear USB |
1 × USB 20Gbps Type-C + 5 × USB 10Gbps (4 × Type-A + 1 × Type-C) + 2 × USB 2.0 Type-A |
| Front USB |
1 × USB 10Gbps Type-C header + 1 × USB 5Gbps header + 1 × USB 2.0 header |
| Display Output |
1 × HDMI 2.1 + USB Ty |
