| CPU |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD B850 |
| Memory |
4 × DDR5 DIMM |
| Max Memory |
256GB |
| Memory Speed |
Up to DDR5-9000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
AMD EXPO™, ASUS AEMP, ECC / Non-ECC |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| Additional PCIe |
1 × PCIe 4.0 x16 (x4 mode) |
| M.2 |
4 × M.2 |
| M.2 PCIe 5.0 |
2 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
2 × PCIe 4.0 x4 |
| SATA |
2 × SATA 6Gb/s |
| LAN |
Realtek 5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Wi-Fi Module |
MediaTek MT7925 |
| Bluetooth |
Bluetooth 5.4, LE Audio |
| Rear USB |
12 × USB |
| Rear USB 10Gbps |
4 × (2 Type-A + 2 Type-C) |
| Rear USB 5Gbps |
6 × (5 Type-A + 1 Type-C) |
| Rear USB 2.0 |
2 × Type-A |
| Front USB 20Gbps |
1 × USB Type-C header |
| HDMI |
HDMI 2.1, up to 4K@60Hz |
| Audio Codec |
ROG SupremeFX / Realtek ALC4080 |
| Audio Amp |
Savitech SV3H712 |
| Optical Audio |
1 × S/PDIF |
| Power Design |
16+2+2 power stages, up to 80A |
| BIOS |
64MB Flash ROM / BIOS FlashBack™ |
| RGB |
3 × Addressable Gen 2 RGB headers |
