| CPU |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD X870 |
| Form Factor |
Mini-ITX |
| Memory |
2 × DDR5 DIMM |
| Max Memory |
128GB |
| Memory Speed |
Up to DDR5-8400+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
AMD EXPO™, ASUS AEMP |
| PCIe |
1 × PCIe 5.0 x16 SafeSlot |
| M.2 |
2 × M.2 |
| M.2 PCIe 5.0 |
1 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
1 × PCIe 4.0 x4 |
| SATA |
2 × SATA 6Gb/s |
| LAN |
Intel 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Bluetooth |
Bluetooth 5.4 |
| USB4 |
2 × USB4 Type-C, up to 40Gbps |
| Rear USB |
USB 10Gbps / USB 5Gbps / USB 2.0 |
| Front USB |
USB 20Gbps Type-C header |
| Audio |
ROG SupremeFX / High Definition Audio |
| Audio Solution |
ROG Strix Hive II |
| Power Design |
10+2+1 power stages |
| BIOS |
BIOS FlashBack™ |
| RGB |
Aura Sync / Addressable Gen 2 RGB |
| Wi-Fi Antenna |
ASUS WiFi Q-Antenna |
