| CPU |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD X870E |
| Memory |
4 × DDR5 DIMM |
| Max Memory |
256GB |
| Memory Speed |
Up to DDR5-8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
AMD EXPO™, ASUS AEMP, NitroPath DRAM |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| Additional PCIe |
1 × PCIe 4.0 x16 (x4 mode) |
| M.2 |
5 × M.2 |
| M.2 PCIe 5.0 |
3 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
2 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Realtek 5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7, 2×2 |
| Wi-Fi Band |
2.4 / 5 / 6GHz |
| Wi-Fi Speed |
Up to 6.5Gbps |
| Bluetooth |
Bluetooth 5.4 |
| USB4 |
2 × USB4 Type-C, up to 40Gbps |
| Rear USB 20Gbps |
1 × USB Type-C, up to 30W PD Fast-Charge |
| Rear USB 10Gbps |
10 × (9 Type-A + 1 Type-C) |
| Front USB 20Gbps |
1 × USB Type-C header |
| Front USB 5Gbps |
2 × headers |
| HDMI |
HDMI 2.1, up to 4K@60Hz |
| Audio |
ROG SupremeFX / Realtek ALC4080 7.1 |
| Audio Amp |
Savitech SV3H712 |
| Optical Audio |
1 × S/PDIF |
| Power Design |
18+2+2 power stages |
| RGB |
3 × Addressable Gen 2 RGB headers |
| BIOS |
BIOS FlashBack™ + Clear CMOS |
