ASUS RT-BE92U WiFi 7 Tri-band Router – Specifications

Model

• ASUS RT-BE92U

Network Standards

• IEEE 802.11a/b/g

• WiFi 4 (802.11n)

• WiFi 5 (802.11ac)

• WiFi 6 (802.11ax)

• WiFi 6E (802.11ax)

• WiFi 7 (802.11be)

• IPv4 & IPv6

Performance

• Product Segment: BE9700 (ultimate BE performance)

  • 2.4GHz: up to 1032 Mbps

  • 5GHz: up to 2882 Mbps

  • 6GHz: up to 5764 Mbps

• Boosts Speed:

  • OFDMA

  • Beamforming (standard & universal)

  • 4096-QAM

  • Bandwidth: 20/40/80/160/320 MHz

Hardware

• Processor: 2.0GHz Quad-core

• Memory: 256 MB Flash + 1 GB DDR4 RAM

• Antenna: 4 × external antennas

• Transmit / Receive:

  • 2.4GHz: 3x3

  • 5GHz: 2x2

  • 6GHz: 2x2

Operating Modes

• Wireless Router Mode

• AiMesh Node Mode

• Access Point Mode

• Media Bridge Mode

• Repeater Mode

I/O Ports

• 1 × 10Gbps WAN/LAN

• 1 × 2.5Gbps WAN/LAN

• 3 × 2.5Gbps LAN

• 1 × USB 3.2 Gen1

Buttons & Indicators

• Buttons: WPS, Reset, Power Switch

• LEDs: Power, WAN, LAN, 2.4GHz, 5GHz, 6GHz

Power

• AC Input: 110V–240V (50–60Hz)

• DC Output: 12V / 3A

Package Contents

• RT-BE92U Router

• Wall Mount Kit

• RJ-45 Cable

• Power Adapter

• Quick Start Guide

• Warranty Card

Dimensions

• Size: 247.18 × 101.59 × 287.47 mm

• Size (inches): 9.73 × 4.00 × 11.32

Features

AiMesh

• Works as Primary AiMesh Router or AiMesh Node

Parental Control

• Website & App Filtering

• Time Scheduling & Safe Browsing

• Max Profiles: 64

• Max Content Filter Rules: 64

Guest Network

• Up to 3 per band (2.4GHz & 5GHz)

• WPA/WPA2/WPA3-Personal, Open system

Security

• AiProtection Pro (Router Security Assessment, Malicious Site Blocking, IPS, Infected Device Blocking)

• WPA/WPA2/WPA3 Personal & Enterprise

• Open System & OWE

• Let’s Encrypt, DNS-over-TLS, SSH, Firewall

• Max Filters:

  • Keyword: 64

  • URL: 64

  • Network Service: 32

VPN

• VPN Client: L2TP, OpenVPN, PPTP, WireGuard

• VPN Server: IPSec, OpenVPN, PPTP, WireGuard

• VPN Fusion & Surfshark Support

• Instant Guard

Traffic Control

• Adaptive QoS (Bandwidth Monitor & Limiter, max 32 rules)

• Traditional QoS

• Traffic Monitor (real-time, wired, wireless)

• Traffic Analyzer (daily, weekly, monthly, website history)

WAN

• Internet Types: PPPoE, PPTP, L2TP, Auto IP, Static IP, IPSec

• Dual WAN

• 3G/4G LTE dongle support

• 4G/5G Auto Mobile Tethering

• Port Forwarding (max 64 rules)

• Port Triggering (max 32 rules)

• DMZ, DDNS

• NAT Passthrough (PPTP, L2TP, IPSec, RTSP, H.323, SIP, PPPoE Relay)

LAN

• DHCP Server

• IGMP Snooping, IPTV

• Manual IP Assignment (max 128 rules)

• Wake-on-LAN (WOL)

Wireless

• MU-MIMO

• UTF-8 SSID

• WiFi MAC Filtering (max 64)

• Wireless Scheduler

• Airtime Fairness

• RADIUS Client

• Beamforming (Universal & Explicit)

USB Applications

• 4G / 5G Auto Tethering

• File Systems: HFS+, NTFS, vFAT, ext2/3/4

• Safely Remove Disk

• AiCloud, Download Master, AiDisk

• Media Server, Time Machine

• Samba & FTP Server

• Shared Folder Privileges

User Interface

• Web: ASUSWRT

• App: ASUS Router App

Administration

• Config Backup & Restore

• Diagnosis Tools, Feedback, System Log

• New Device Notification

• Login Captcha

• Auto Firmware Update
