| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series |
| Chipset |
AMD B850 |
| Form Factor |
ATX — 30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
256GB |
| Memory Speed |
Up to 8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS AEMP |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| Additional PCIe Slots |
1 × PCIe 4.0 x16 (x4 mode) + 1 × PCIe 4.0 x1 |
| M.2 Slots |
4 × M.2 |
| M.2 Gen5 |
2 × PCIe 5.0 x4 |
| M.2 Gen4 |
2 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Realtek 5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Wi-Fi Configuration |
2×2, 160MHz |
| Bluetooth |
Bluetooth 5.4 |
| Rear USB |
USB 10Gbps / USB 5Gbps / USB 2.0 |
| Front USB |
USB 20Gbps Type-C header + USB 5Gbps headers |
| Display Output |
HDMI 2.1 + DisplayPort |
| Audio |
Realtek 7.1-channel HD Audio |
| Power Design |
TUF Gaming VRM power design |
| BTF Design |
Back-to-the-Future (BTF) rear-connector design |
| BIOS |
UEFI AMI BIOS |
| RGB |
Addressable Gen 2 RGB headers |
