| CPU Socket |
AMD AM5 |
| CPU Support |
AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Chipset |
AMD B850 |
| Form Factor |
ATX — 30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
256GB |
| Memory Speed |
Up to 8000+ MT/s (OC) |
| Memory Architecture |
Dual Channel |
| Memory Support |
ECC / Non-ECC Unbuffered, AMD EXPO, ASUS AEMP |
| Main PCIe Slot |
1 × PCIe 5.0 x16 |
| Additional PCIe Slots |
1 × PCIe 4.0 x16 (x4 mode) + 2 × PCIe 4.0 x1 |
| M.2 Slots |
3 × M.2 |
| M.2 Gen5 |
1 × PCIe 5.0 x4 |
| M.2 Gen4 |
2 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Realtek 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7 |
| Wi-Fi Configuration |
2×2, 160MHz, up to 2.9Gbps |
| Bluetooth |
Bluetooth 5.4 |
| Rear USB |
1 × USB 20Gbps Type-C + 3 × USB 10Gbps Type-A + 4 × USB 5Gbps Type-A + 2 × USB 2.0 Type-A |
| Front USB |
1 × USB 10Gbps Type-C header + 1 × USB 5Gbps header + 2 × USB 2.0 headers |
| Display Output |
1 × DisplayPort 1.4 + 1 × HDMI 2.1 |
| Audio |
Realtek ALC1220P 7.1 Surround Sound HD Audio |
| Audio Quality |
Up to 120dB SNR playback / 113dB SNR recording |
| Power Design |
DIGI+ VRM with DrMOS |
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS |
| BIOS FlashBack |
Yes |
| RGB |
3 × Addressable Gen 2 RGB headers |
| Thunderbolt / USB4 |
1 × Thunderbolt™ / USB4® header |
| Operating (ASUS Global) |
|
