| Brand |
ASUS |
| Series |
TUF GAMING |
| Model |
TUF GAMING Z890-PRO WIFI |
| Part Number |
90MB1IR0-M0UAY0 |
| Colour |
White / Silver |
| CPU Socket |
Intel LGA1851 |
| CPU Support |
Intel Core Ultra Processors (Series 2) |
| Chipset |
Intel Z890 |
| Form Factor |
ATX |
| Motherboard Size |
30.5 × 24.4 cm |
| Memory |
4 × DDR5 DIMM |
| Maximum Memory |
Up to 256GB |
| Memory Speed |
Up to DDR5-9066+ MT/s (OC) |
| Memory Features |
XMP, ASUS AEMP III, DIMM Fit / DIMM Fit Pro, CUDIMM |
| PCIe x16 |
1 × PCIe 5.0 x16 |
| Additional PCIe |
1 × PCIe 4.0 x16 (x4), 1 × PCIe 4.0 x4, 2 × PCIe 4.0 x1 |
| M.2 Slots |
4 |
| M.2 PCIe 5.0 |
1 × PCIe 5.0 x4 |
| M.2 PCIe 4.0 |
3 × PCIe 4.0 x4 |
| SATA |
4 × SATA 6Gb/s |
| LAN |
Intel 2.5Gb Ethernet |
| Wi-Fi |
Wi-Fi 7, 2×2 |
| Bluetooth |
Bluetooth 5.4 |
| Thunderbolt |
2 × Thunderbolt 4 USB-C |
| Rear USB |
2 × Thunderbolt 4 + 6 × USB 10Gbps Type-A |
| Front USB-C |
USB 20Gbps, up to 30W PD/PPS fast charging |
| Audio |
Realtek ALC1220P 7.1-channel HD Audio |
| Display Output |
DisplayPort + HDMI 2.1 |
| RGB |
ASUS Aura Sync / Addressable Gen 2 RGB |
| Power Design |
16+1+2+1 power stages, 80A |
| BIOS |
256Mb Flash ROM, UEFI AMI BIOS |
