| Graphics Engine |
NVIDIA GeForce RTX 5080 |
| GPU Architecture |
NVIDIA Blackwell |
| CUDA Cores |
10,752 |
| AI Performance |
1,801 TOPs |
| Bus Standard |
PCI Express 5.0 |
| OpenGL |
OpenGL 4.6 |
| Video Memory |
16GB GDDR7 |
| Memory Speed |
30 Gbps |
| Memory Interface |
256-bit |
| Engine Clock – OC Mode |
2730 MHz |
| Engine Clock – Default Mode |
2700 MHz (Boost Clock) |
| Digital Max Resolution |
7680 × 4320 |
| Display Outputs |
3 × DisplayPort 2.1b |
| Maximum Displays |
4 |
| HDCP Support |
HDCP 2.3 |
| NVLink / CrossFire |
No |
| Cooling |
Triple Axial-tech Fans + Vapor Chamber |
| Dimensions |
348 × 146 × 72 mm |
| Slot Thickness |
3.6-Slot |
| Power Connector |
1 × 16-pin |
| Recommended PSU |
850W |
| Lighting |
ARGB / Aura Sync |
| Software |
ASUS GPU Tweak III, MuseTree, GeForce Game Ready Driver, Studio Driver |
| Model / PN |
TUF-RTX5080-O16G-GAMING / 90YV0M30-M0NA00 |
