| Model |
MasterBox NR200 |
| Black Part Number |
MCB-NR200-KNNN-S00 |
| White Part Number |
MCB-NR200-WNNN-S00 |
| Case Type |
Mini-ITX / SFF |
| Colour |
Black / White |
| Materials |
Steel / Plastic / Mesh |
| Dimensions (L × W × H) |
376 × 185 × 292 mm |
| Dimensions Without Protrusions |
360 × 185 × 274 mm |
| Volume |
18.25 L |
| Motherboard Support |
Mini-ITX / Mini-DTX |
| Maximum Motherboard Size |
244 × 226 mm |
| Expansion Slots |
3 |
| PSU Support |
SFX / SFX-L |
| CPU Cooler Clearance |
155 mm |
| CPU Cooler Clearance with Vertical GPU |
76 mm |
| GPU Length Clearance |
330 mm including power connector |
| GPU Height Clearance |
156 mm including power connector |
| GPU Width Clearance |
60 mm / Triple-Slot |
| Weight |
4.8 kg |
| 3.5" Drive Bays |
1 (Max. 2) |
| 2.5" Drive Bays |
2 (Max. 3) |
| 2.5" / 3.5" Combo Bay |
1 |
| Top Fan Support |
2 × 120 mm |
| Side Fan Support |
2 × 120/140 mm |
| Bottom Fan Support |
2 × 120 mm |
| Rear Fan Support |
1 × 92 mm |
| Pre-installed Top Fan |
1 × 120 mm SickleFlow PWM |
| Pre-installed Rear Fan |
1 × 92 mm SickleFlow PWM |
| Front Fan Support |
None |
| Top Radiator Support |
None |
| Side Radiator Support |
120 / 140 / 240 / 280 mm |
| Bottom Radiator Support |
120 / 240 mm |
| Rear Radiator Support |
92 mm |
| Front I/O |
2 × USB 3.2 Gen 1 Type-A |
| Audio |
1 × 3.5 mm Headset Jack |
| Dust Filters |
Top / Bottom / Left / Right |
| PCIe Riser Cable |
Not included |
| Warranty |
2 Years |
