| Specification | Details |
|---|---|
| Model | MWE Gold 1050 V2 ATX 3.1 |
| Part Number | MPE-A501-AFCAG-3EUK |
| Power Output | 1050W |
| Form Factor | ATX |
| ATX Version | ATX 3.1 |
| Efficiency Rating | 80 PLUS Gold |
| Modular | Fully Modular |
| PFC | Active PFC |
| Input Voltage | 100–240V |
| Input Current | 13–6A |
| Input Frequency | 50–60Hz |
| Dimensions (L × W × H) | 180 × 150 × 86 mm |
| Fan Size | 140 mm |
| Fan Bearing | FDB |
| Fan Speed | Up to 2200 RPM |
| Efficiency | ≥90% @ Typical Load |
| Operating Temperature | 0–50°C |
| Power Good Signal | 100–150 ms |
| Hold-Up Time | ≥16 ms at 100% Load |
| MTBF | >100,000 Hours |
| 12V-2x6 Connector | 1 |
| PCIe 6+2-pin Connectors | 3 |
| EPS 4+4-pin Connector | 1 |
| EPS 8-pin Connector | 1 |
| SATA Connectors | 12 |
| Peripheral 4-pin Connectors | 4 |
| ATX 24-pin Connector | 1 |
| Protections | OVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection |
| Warranty | 10 Years |
