| Model |
QUBE 540 |
| Part Number |
Q540-LGNN-S00 |
| Case Type |
Mid Tower |
| Colour |
Moonstone |
| Materials |
Steel / Tempered Glass |
| Side Panel |
Left: Tempered Glass / Right: Steel |
| Dimensions (L × W × H) |
438.5 × 225 × 492.1 mm |
| Dimensions Without Protrusions |
425 × 225 × 425 mm |
| Volume |
40.64 L without protrusions / 48.55 L with panel, protrusions and feet |
| Motherboard Support |
ITX / Micro-ATX / ATX / E-ATX |
| E-ATX Support |
Up to 280 mm |
| Expansion Slots |
7 |
| 3.5" HDD Bays |
1 × (shared 3.5"/2.5" mounting) |
| 2.5" SSD Bays |
2 × standard / up to 5 × maximum |
| Front Fan Support |
3 × 120 mm / 2 × 140 mm |
| Top Fan Support |
3 × 120 mm / 2 × 140 mm |
| Rear Fan Support |
1 × 120 mm |
| Bottom Fan Support |
3 × 120 mm / 2 × 140 mm |
| Pre-installed Fans |
1 × 120 mm Black Fan at Rear |
| Front Radiator Support |
140 / 280 / 360 mm |
| Top Radiator Support |
140 / 280 / 360 mm |
| Bottom Radiator Support |
140 / 280 / 360 mm |
| Rear Radiator Support |
120 mm |
| Maximum CPU Cooler Height |
172 mm |
| Maximum GPU Length |
415 mm (without front fan) |
| Maximum PSU Length |
200 mm |
| Cable Routing Space |
27 mm |
| PSU Support |
ATX / SFX |
| Front I/O |
2 × USB 3.2 Gen 1 Type-A + 1 × USB 3.2 Gen 2×2 Type-C |
| Audio |
1 × 3.5 mm Mic / Audio Combo Jack |
| Dust Filters |
Top / Bottom / Front |
| Vertical GPU Support |
Yes |
| Warranty |
2 Years |
