| Model |
Prompter |
| SKU |
CS-10WAD9901 / 10WAD9901 |
| Product Type |
All-in-One Teleprompter |
| Display |
9" Integrated Display |
| Resolution |
1024 × 600 |
| Refresh Rate |
60 Hz |
| Brightness |
400 nits |
| Glass |
70/30 Beamsplitter Glass |
| Glass Size |
1.1 × 200 × 180 mm |
| Interface |
USB-C (USB 3.0) |
| Power Consumption |
4.5W |
| Recommended Reading Distance |
Up to 1.8 m / 6 ft |
| Mounting Points |
2 × 1/4" Threads |
| Cold Shoe Mounts |
2 |
| Camera Bracket |
Universal L-Bracket |
| Max Camera + Lens Length |
11 cm / 4.3" |
| Max Lens Clearance |
85 mm |
| Max Camera Load |
3 kg / 6.6 lbs |
| Supported Lens Sizes |
49 / 52 / 55 / 58 / 62 / 67 / 72 / 77 / 82 mm |
| Camera Support |
DSLR, Mirrorless, Webcam, Smartphone, Camcorder, Action Camera* |
| Backplates Included |
DSLR/Mirrorless, Facecam Pro, Universal |
| Software |
Elgato Camera Hub |
| Script Manager |
Yes |
| Display Mode |
Can be used as an additional monitor |
| Voice Sync |
Yes |
| Twitch Chat Integration |
Yes |
| Stream Deck Integration |
Yes |
| Body Material |
Polymer |
| Dimensions |
224 × 219 × 282 mm |
| Weight |
690 g (without accessories) |
| Cable |
USB-C to USB-A 3.0, 200 cm |
| Windows |
Windows 11 or newer |
| macOS |
macOS 13.3 Ventura or newer |
| Android |
Android 11 or newer |
| Voice Sync Requirement |
NVIDIA RTX 2060 or newer / Apple M1 or newer |
| In the Box |
Prompter, DSLR/Mirrorless Backplate, 9 Step-up Rings, Facecam Pro Backplate, Universal Shroud Backplate, Universal Bracket, Mounting Screws, USB-C to USB-A Cable, Cleaning Cloth, Quick Start Guide |
