Core Engine & Architecture
-
Graphics Processor: NVIDIA GeForce RTX 5060 Ti
-
GPU Architecture: NVIDIA Blackwell Architecture
-
CUDA Cores: 4,608
-
Core Clock Speed: 2647 MHz (Factory Overclocked vs. 2572 MHz Reference Layout)
-
Tensor Cores: 5th Generation
-
Ray Tracing Cores: 4th Generation
Memory Profile
-
Memory Size: 8 GB
-
Memory Type: Next-Gen GDDR7
-
Memory Bus Interface: 128-bit
-
Effective Memory Clock: 28 Gbps
System Interface & Connectivity
-
Bus Type: PCI Express 5.0
-
Video Outputs:
-
3x DisplayPort 2.1b
-
1x HDMI 2.1b
-
-
Maximum Digital Resolution: 7680 x 4320 (8K Ultra HD)
-
Multi-View Capability: Up to 4 concurrent monitors
