Core Specifications
-
Form Factor: ATX Mid-Tower
-
Motherboard Support: SSI-EEB (max 330mm), E-ATX (max 280mm), ATX, Micro-ATX, Mini-ITX (Supports Back-Connect / BTF ATX & Micro-ATX boards)
-
Materials: Steel, 4.0mm Tempered Glass, Plastic
-
Drive Bays: Up to 5× 2.5" SSDs or 4× 3.5" HDDs (via drive cages and behind motherboard tray)
-
Expansion Slots: 7
Clearances
-
Max GPU Length: Up to 380 mm
-
Max CPU Cooler Height: Up to 180 mm
-
Max PSU Length: Up to 220 mm (Standard Mode) / Up to 180 mm (Rotated Mode)
Cooling & Fan Support
-
Pre-installed Fans:
-
Front: 2× 170mm ARGB fans with infinity mirror hubs
-
Rear: 1× 140mm ARGB fan
-
-
Top Fan/Radiator Support: 3× 120mm or 2× 140mm fans; Radiators up to 360mm / 280mm
-
PSU Shroud Fan Support: Up to 3× 120mm above shroud + 2× 120mm inside bottom chamber
Front I/O Ports
-
1× USB 3.2 Gen 2x2 Type-C
-
2× USB 3.0 Type-A
-
1× 3.5mm Headphone/Microphone Combo Audio Jack
-
Built-in Fan / ARGB Control Buttons
