| Model / SKU |
LL 6017 |
LL 6018 |
| Official Model |
RS1000G.BH00 / RS1000G.B000* |
RS1000G.WH00 / RS1000G.W000* |
| Product Type |
ATX Power Supply |
ATX Power Supply |
| Power Output |
1000W |
1000W |
| Efficiency |
80 PLUS Gold |
80 PLUS Gold |
| Cybenetics Efficiency |
Platinum |
Platinum |
| Modular |
Fully Modular |
Fully Modular |
| ATX Version |
ATX 3.1 |
ATX 3.1 |
| PCIe Standard |
PCIe 5.1 Ready |
PCIe 5.1 Ready |
| GPU Power Connector |
Native 12V-2×6 |
Native 12V-2×6 |
| 24-Pin Output |
Dual-sided 20+4-pin |
Dual-sided 20+4-pin |
| AC Input |
90° Rotatable |
90° Rotatable |
| Input Voltage |
100–240V AC |
100–240V AC |
| Input Current |
15–8A |
15–8A |
| Input Frequency |
50–60Hz |
50–60Hz |
| PFC |
Active PFC |
Active PFC |
| Dimensions |
150 × 86 × 150 mm |
150 × 86 × 150 mm |
| Fan |
135mm FDB |
135mm FDB |
| Max Fan Speed |
1600 RPM |
1600 RPM |
| Fanless Mode |
Yes |
Yes |
| Noise Level |
36.21 dBA @ 30°C / 100cm |
36.21 dBA @ 30°C / 100cm |
| +12V Output |
1000W |
1000W |
| +3.3V + +5V Output |
100W |
100W |
| Capacitors |
German EPCOS industrial-grade |
German EPCOS industrial-grade |
| Protection |
OCP / OVP / OTP / OPP / SCP / UVP / NLP / SIP |
OCP / OVP / OTP / OPP / SCP / UVP / NLP / SIP |
| Operating Temperature |
0–40°C |
0–40°C |
| MTBF |
≥100,000 hours |
≥100,000 hours |
| Warranty |
10 Years |
10 Years |
