| Specification | Details |
|---|---|
| Model | SP1000P |
| Product Type | SFX Power Supply |
| Power Output | 1000W |
| Efficiency Certification | 80 PLUS Platinum |
| Modular | Fully Modular |
| Form Factor | SFX |
| Color | Black |
| ATX Version | ATX 3.1 |
| PCIe Standard | PCIe 5.1 |
| GPU Connector | 12V-2×6, 600W |
| +12V Output | 999.6W |
| +3.3V + +5V Output | 100W |
| Input Voltage | 100–240V AC |
| Input Frequency | 50–60Hz |
| Input Current | 6–12A |
| PFC | Active PFC, PF >0.95 |
| Fan | 92mm FDB |
| Max Fan Speed | 2900 RPM |
| Fanless Mode | Yes, below 40% load |
| Max Noise | 45 dBA |
| Capacitors | 100% Japanese Rubycon 105°C |
| Protection | OPP / NLP / OVP / SCP / UCP / OTP / UVP / SIP |
| Dimensions | 125 × 63.5 × 100 mm |
| Material | SECC |
| SFX-to-ATX Bracket | Included |
| Operating Temperature | 0–40°C |
| Warranty | 10 Years |
