| Specification | Black | White |
|---|---|---|
| Model / SKU | SP850v2 Gold Black | SP850v2 Gold White |
| Official Model | SP850G | SP850G |
| Product Type | SFX Power Supply | SFX Power Supply |
| Power Output | 850W | 850W |
| Efficiency Certification | 80 PLUS Gold | 80 PLUS Gold |
| Modular | Fully Modular | Fully Modular |
| Form Factor | SFX | SFX |
| ATX Version | ATX 3.1 | ATX 3.1 |
| PCIe Standard | PCIe 5.0 Ready | PCIe 5.0 Ready |
| GPU Connector | Native 12V-2×6 | Native 12V-2×6 |
| +12V Output | 840W | 840W |
| +3.3V + +5V Output | 100W | 100W |
| Input Voltage | 100–240V AC | 100–240V AC |
| Input Frequency | 50–60Hz | 50–60Hz |
| PFC | Active PFC | Active PFC |
| Fan | 92mm FDB | 92mm FDB |
| Fan Speed | Up to 3000 RPM | Up to 3000 RPM |
| Fanless Mode | Yes | Yes |
| Dimensions | 125 × 100 × 63.5 mm | 125 × 100 × 63.5 mm |
| Capacitors | Japanese Electrolytic Capacitors | Japanese Electrolytic Capacitors |
| Cable Type | Fully Modular | Fully Modular |
| Protection | OCP / OVP / OTP / OPP / SCP / UVP / NLP / SIP | OCP / OVP / OTP / OPP / SCP / UVP / NLP / SIP |
| Operating Temperature | 0–40°C | 0–40°C |
| Warranty | 10 Years | 10 Years |
