Key Specifications
| Specification | Details |
|---|---|
| Case Type | Mid-Tower |
| Motherboard Support | E-ATX (up to 280mm wide), ATX, Micro-ATX, Mini-ITX |
| Dimensions (LxWxH) | 540mm × 262mm × 572mm |
| Materials | Steel chassis, 6000 & 5000-series Anodized Aluminum, 4mm Tempered Glass |
| Max GPU Length | Up to 460mm |
| Max CPU Cooler Height | 170mm |
| Max PSU Length | Up to 190mm (ATX) |
| Drive Bays | 2 × 3.5" HDD, 9 × 2.5" SSD |
| Expansion Slots | 7 |
| Front I/O | 4× USB 3.2 Gen 1 Type-A, 1× USB 3.2 Gen 2x2 Type-C, Audio In/Out |
Cooling & Radiator Support
- Top: 240mm (Up to 420mm if PSU is bottom mounted)
- Side: 240mm / 280mm / 360mm / 420mm
- Bottom: 240mm / 280mm / 360mm
- Rear: 1× 120mm
Special Features
- Modular Layout: The PSU shroud and motherboard tray are completely removable and can be repositioned at the top or bottom.
- BTF/Stealth Support: Supports back-connect motherboards when configured with a bottom-mounted PSU.
- Floating Aesthetic: Designed with a raised, X-shaped floating base to improve bottom intake.
