🔥 Core GPU & Performance
-
GPU Model: NVIDIA GeForce RTX 5070 Ti (Blackwell architecture)
-
CUDA Cores: 8,960 — strong parallel compute performance for gaming and GPU workloads
-
Base / Boost Clock: ~2295 MHz / ~2452 MHz factory clocks
-
PCIe Interface: PCIe 5.0 ×16 for latest motherboard compatibility
-
TDP / Power: ~300 W with 16‑pin power connector (requires ~750 W PSU)
🧠Memory & Bandwidth
-
VRAM: 16 GB GDDR7 high‑speed memory — excellent for 4K gaming and large content workloads
-
Bus Width: 256‑bit
-
Effective Memory Speed: ~28 Gbps (896 GB/s bandwidth)
🎮 NVIDIA Technologies (RTX Feature Set)
-
DLSS 4 — AI upscaling for higher FPS at high resolutions
-
RTX Ray Tracing with 4th‑Gen RT Cores and 5th‑Gen Tensor Cores
-
Reflex 2, Broadcast, Resizable BAR, NVIDIA Studio / G‑SYNC support
-
DirectX 12 Ultimate and other modern API support
❄️ Cooling & Build
-
Triple‑fan cooling with advanced heat pipes (TurboFan 4.0 / composite heat pipe design) for thermal performance
-
0 dB Mode (fans stop at low temps) and Dual BIOS (Performance/Silent modes) on some variants
-
ARGB lighting and a stylish industrial look with customizable sync headers
-
2.5‑slot form factor — balance of cooling and size
🖥️ Display & Outputs
-
DisplayPorts: 3× DisplayPort 2.1b
-
HDMI: 1× HDMI 2.1b for high‑refresh 4K/8K output
-
Max Resolution: Up to 7680 × 4320 or 4K at high refresh rates with DSC
-
Multi‑monitor Support: Up to 4 displays
đź’ˇ Ideal For
-
High‑end 1440p & 4K gaming, ray‑traced titles
-
Content creation workloads that benefit from large VRAM and AI acceleration
-
Future‑ready graphics with modern features like DLSS 4 and PCIe 5.0
