| Model |
PH-P1000GH_WT01_UK |
| Product Name |
AMP GH 1000W |
| Color |
White |
| Power Output |
1000W |
| Efficiency Rating |
80 PLUS Platinum |
| Form Factor |
ATX |
| Platform |
Intel ATX 3.1 / PCIe Gen5.1 |
| Modularity |
Fully Modular |
| PCIe Gen5 Output |
Up to 600W |
| GPU Connector |
1 × 12V-2×6 |
| Dimensions |
140 × 150 × 86 mm |
| Cooling Fan |
120mm Hydraulic Dynamic Bearing Fan |
| Fan Mode |
Hybrid Fanless Mode |
| Fanless Operation |
Below 30% load |
| MTBF |
>100,000 hours @ 25°C |
| +12V Output |
83A / 996W |
| +5V Output |
20A / 100W |
| +3.3V Output |
20A / 66W |
| +3.3V + +5V Combined |
120W |
| -12V Output |
0.3A / 3.6W |
| +5VSB |
3A / 15W |
| Input Voltage |
100–240V |
| Mainboard Connector |
1 × 18+10-pin |
| CPU / PCIe Connectors |
6 × 8-pin |
| SATA / Molex Connectors |
4 × 6-pin |
| 12V-2×6 Connector |
1 × |
| Protection |
OPP, OVP, UVP, SCP, OCP, OTP, No-Load, Reset |
| Mainboard Cable |
1 × 18+10-pin → 24-pin, 610mm |
| CPU Cables |
2 × 4+4-pin, 650mm |
| PCIe Cables |
4 × 6+2-pin, 750mm |
| 12V-2×6 Cable |
1 × 720mm |
| SATA Cables |
2 × 4-SATA + 1 × 2-SATA/Molex |
| Net Weight |
2.33 kg |
| Warranty |
8 Years Limited |
