| Specification | Details |
|---|---|
| Model / SKU | PH-P850GH_BK01_UK |
| Product Name | AMP GH 850W |
| Color | Black |
| Power Output | 850W |
| Efficiency Rating | 80 PLUS Gold |
| Form Factor | ATX |
| Platform | Intel ATX 3.1 / PCIe Gen5.1 |
| Modularity | Fully Modular |
| PCIe Gen5 Output | Up to 450W |
| GPU Connector | 1 × 12V-2×6 |
| Dimensions | 140 × 150 × 86 mm |
| Cooling Fan | 120mm Hydraulic Bearing Fan |
| Fan Mode | Hybrid Fanless Mode |
| Fanless Operation | Below 30% load |
| MTFB | >100,000 hours @ 25°C |
| +12V Output | 70A / 840W |
| +5V Output | 20A / 100W |
| +3.3V Output | 20A / 66W |
| +3.3V + +5V Combined | 100W |
| -12V Output | 0.3A / 3.6W |
| +5VSB | 2.5A / 12.5W |
| Input Voltage | 100–240V |
| Mainboard Connector | 1 × 18+10-pin |
| CPU / PCIe Connectors | 6 × 8-pin |
| SATA / Molex Connectors | 4 × 6-pin |
| 12V-2×6 Connector | 1 × |
| Protection | OPP, OVP, UVP, SCP, OCP, OTP, No-Load, Reset |
| Mainboard Cable | 1 × 18+10-pin, 600mm |
| CPU Cables | 2 × 4+4-pin, 700mm |
| PCIe Cables | 3 × 6+2-pin, 750mm |
| 12V-2×6 Cable | 1 × 720mm |
| SATA Cables | 1 × 4-SATA + 1 × 2-SATA + 2-Molex |
| Net Weight | 1.40 kg |
| Warranty | 8 Years Limited |
