| Model / SKU |
PH-F120D30_DRGB_PWM_BK01_3P |
| Color |
Black |
| Pack Quantity |
3 Fans |
| Fan Size |
120 × 120 × 30 mm |
| Fan Type |
Regular Airflow |
| Blade Design |
7 blades |
| Bearing Type |
FDB (Fluid Dynamic Bearing) |
| Fan Speed |
250–2000 ±10 RPM |
| Max Airflow |
64.3 CFM |
| Max Air Pressure |
3.01 mmH₂O |
| Noise Level |
30.2 dBA |
| PWM Connector |
4-Pin Daisy-Chain |
| PWM Cable Length |
700 mm |
| D-RGB Connector |
3-Pin JST Daisy-Chain |
| D-RGB Cable Length |
600 + 100 mm |
| D-RGB LEDs |
30 per fan |
| LED Rated Current |
Max. 0.45 A |
| Rated Voltage |
5–13.2 V |
| Max Current |
0.15 A |
| Max Power |
≤1.8 W |
| MTFB |
50,000 hours |
| Daisy-Chain |
Up to 4 D30 fans |
| Radiator Support |
Yes |
| Mesh / Dust Filter Support |
Yes |
| Net Weight |
300 g* |
| Gross Weight |
990 g |
| Warranty |
3 Years Limited |
