| Model |
PH-ES524S2_DWT01 |
| Product Name |
Evolv S2 |
| Color |
White |
| Case Type |
Mid-Tower |
| Dimensions |
455 × 230 × 525 mm |
| Materials |
Steel Chassis, Tempered Glass, ABS |
| Motherboard Support |
E-ATX, ATX, Micro-ATX, Mini-ITX |
| Max E-ATX Width |
280 mm |
| Rear-Connect Motherboard |
Yes, ATX |
| Expansion Slots |
7 |
| Vertical GPU Support |
Yes |
| Vertical GPU Bracket |
Optional |
| Max GPU Length |
395 mm |
| Max GPU Width |
175 mm |
| Max CPU Cooler Height |
175 mm |
| Max PSU Length |
210 mm |
| 3.5" Drive Bays |
2 |
| 2.5" Drive Bays |
2 |
| Fan Support |
Up to 7 × 120 mm |
| Top Fan Support |
3 × 120 mm |
| Bottom Fan Support |
3 × 120 mm |
| Rear Fan Support |
1 × 120 mm |
| Included Fans |
4 × M25-120 D-RGB |
| Included Fan Configuration |
1 × Regular + 3 × Reverse |
| Top Radiator Support |
Up to 360 mm |
| Max Top Radiator Size |
410 × 125 × 55 mm |
| D-RGB |
Integrated D-RGB light strip |
| Front I/O |
2 × USB 3.0, 1 × USB-C 3.2 Gen2x2 |
| Audio |
Microphone/Headphone Combo |
| Buttons |
Power + Reset |
| Net Weight |
9.9 kg |
| Warranty |
5 Years Limited |
