| Model |
Evolv X2 |
| Part Number |
PH-ES524XTG_DBK01 |
| Colour |
Brushed Black Aluminium |
| Case Type |
Mid-Tower |
| Dimensions (D × W × H) |
454 × 228 × 588 mm |
| Materials |
Steel Chassis + Aluminium Panels + Tempered Glass |
| Motherboard Support |
E-ATX / ATX / Micro-ATX / Mini-ITX |
| Max E-ATX Width |
280 mm |
| Rear-Connect Motherboards |
Supported — MSI Project Zero / ASUS BTF / Gigabyte Project Stealth |
| Expansion Slots |
8 |
| Vertical GPU Support |
Yes |
| GPU Riser |
Optional / sold separately |
| GPU Length |
Up to 380 mm |
| GPU Width |
Up to 175 mm |
| CPU Cooler Height |
Up to 170 mm |
| PSU Length |
Up to 250 mm |
| 2.5" Drive Positions |
5 |
| 3.5" Drive Positions |
2 |
| Included Fans |
None |
| Top Fan Support |
3 × 120 mm |
| Bottom Fan Support |
3 × 120 mm |
| Rear Fan Support |
1 × 120 mm |
| Maximum Fans |
7 × 120 mm |
| Top Radiator |
Up to 360 mm |
| Bottom Radiator |
Not supported |
| Rear Radiator |
Not supported |
| D-RGB |
Integrated |
| D-RGB Sync |
Motherboard synchronization |
| Front I/O |
2 × USB 3.0 + 1 × USB-C 3.2 Gen2x2 |
| Audio |
Microphone / Headphone Combo |
| Controls |
Power / Reset |
| Tempered Glass |
Yes |
| Net Weight |
14.2 kg |
| Gross Weight |
16.5 kg |
| Warranty |
5 Years |
