| Specification | Details |
|---|---|
| Model / SKU | PH-F120M25_G2_DWT01_3P |
| Product Name | M25 G2-120 |
| Color | White |
| Pack Quantity | 3 Fans |
| Fan Type | High-Airflow PWM Fan |
| Dimensions | 120 × 120 × 25 mm |
| Blade Design | 9 Blades |
| Bearing Type | Hydraulic Bearing |
| Connector | Linq6 |
| Fan Speed | 350–2000 ±10 RPM |
| Max Airflow | 72.72 CFM |
| Max Static Pressure | 2.51 mmH₂O |
| Max Noise | 35.13 dBA |
| Rated Voltage | 12V |
| Max Motor Current | 0.23A |
| Fan Power | 2.76W |
| Operating Voltage | 7–13.2V |
| MTTF | 40,000 Hours @ 50°C |
| D-RGB | Yes |
| D-RGB LEDs | 12 LEDs per fan |
| D-RGB Voltage | 5V |
| D-RGB Max Current | 0.43A |
| Daisy-Chain | Yes |
| Linq6 Cable | 120mm |
| Extension Cable | 1 × 500mm Linq6 |
| Screw Covers | 4 × Corner + 2 × Bridge per pack |
| Fan Screws | 5 per fan |
| Pack Weight | 464g |
| Ecosystem | Phanteks NexLinq |
| Warranty | 3 Years |
