| Model / SKU |
PH-F140T30_BG |
| Color |
Grey |
| Pack Quantity |
1 Fan |
| Fan Size |
140 × 140 × 30 mm |
| Blade Design |
7 Blades |
| Blade / Frame Material |
Glass Fiber Reinforced LCP |
| Bearing Type |
VAPO Bearing System |
| Motor |
3-Phase Motor, 6-Pole |
| Fan Speed |
0–2500 ±10 RPM |
| Max Airflow |
140.0 CFM |
| Max Air Pressure |
5.41 mmH₂O |
| Max Noise Level |
44.3 dBA |
| PWM Connector |
4-Pin Daisy-Chain |
| PWM Cable |
150 mm + 500 mm Extension |
| D-RGB |
No |
| Rated Voltage |
12 V |
| Max Current |
0.56 A |
| Max Power |
6.72 W |
| Operating Voltage |
DC 10.2–13.2 V |
| MTFB |
150,000 hours |
| Fan Thickness |
30 mm |
| Hybrid Mode |
Up to 1200 RPM / 0 RPM below 50% PWM |
| Performance Mode |
Up to 2000 RPM |
| Advanced Mode |
Up to 2500 RPM |
| Hybrid Airflow |
63.2 CFM |
| Performance Airflow |
109.9 CFM |
| Advanced Airflow |
139.6 CFM |
| Hybrid Static Pressure |
1.34 mmH₂O |
| Performance Static Pressure |
3.58 mmH₂O |
| Advanced Static Pressure |
5.41 mmH₂O |
| Hybrid Noise |
23.2 dBA |
| Performance Noise |
38.1 dBA |
| Advanced Noise |
44.3 dBA |
| Net Weight |
405 ± 5 g |
| Gross Weight |
467 ± 5 g |
| Warranty |
6 Years |
