| Model / SKU |
PH-F140T30_BG_3P |
| Color |
Grey |
| Pack Quantity |
3 Fans |
| Fan Size |
140 × 140 × 30 mm |
| Blade Design |
7 Blades |
| Bearing Type |
VAPO Bearing System |
| Fan Material |
Glass Fiber Reinforced LCP |
| Fan Frame Thickness |
30 mm |
| Fan Speed |
0–2500 ±10% RPM |
| Fan Profiles |
Hybrid / Performance / Advanced |
| Max Airflow |
140.0 CFM |
| Max Air Pressure |
5.41 mmH₂O |
| Max Noise Level |
44.3 dBA |
| PWM Connector |
4-Pin Daisy-Chain |
| PWM Cable |
150 mm + 500 mm Extension |
| Rated Voltage |
12 V |
| Max Current |
0.56 A |
| Max Power |
6.72 W |
| Operating Voltage |
DC 10.2–13.2 V |
| MTFB |
150,000 hours |
| D-RGB |
No |
| Hybrid Mode |
Up to 1200 RPM / 0 RPM below 50% PWM |
| Performance Mode |
Up to 2000 RPM |
| Advanced Mode |
Up to 2500 RPM |
| Net Weight |
1110 ±5 g |
| Gross Weight |
1402 ±5 g |
| Warranty |
6 Years |
