Core Specifications
- Dimensions: 481mm D × 240mm W × 501mm H
- Volume: 58 Liters
- Materials: Steel, plastic, tempered glass, and breathable fabric
- Motherboard Support: ATX, Micro-ATX, Mini-ITX, and back-connect motherboards (e.g., ASUS BTF, MSI Project Zero)
- PCIe Slots: 7
Clearance & Compatibility
- Max GPU Length: Up to 420mm (or 360mm with the pre-installed Cross-Flow Fan attached)
- Max CPU Cooler Height: 170mm
- Max PSU Length: 200mm (Standard ATX supported)
- Storage: Holds either 4 × 2.5” SSDs or 4 × 3.5” HDDs using removable modular drive cages
Cooling & Fan Support
- Front: Pre-installed Cross-Flow Fan (or 3 × 120mm / 2 × 140/160/180/200mm fans)
- Top: 3 × 120mm or 2 × 140mm fans
- Side: 2 × 120mm or 2 × 140mm fans
- Bottom: 2 × 120mm fans
- Rear: 1 × 120mm fan (pre-installed)
- Radiator Support: Front (up to 360/280mm), Top (up to 360/280mm), Side (up to 280mm)
- Cross-Flow Fan Modes: Eco, Performance, and Overdrive (PWM controlled)
Front I/O & Features
- Ports: 2 × USB-A 3.2 Gen 1, 1 × USB-C 3.2 Gen 2×2, 1 × Audio/Mic combo jack
- Cable Management: 40mm of routing space behind the motherboard tray with cable hooks
- Dust Filters: Top, bottom, front, and side
